SSANGYONG 1999 Musso Service Manual page 622

1F1-52 M162 ENGINE CONTROLS
8. Remove the injectors and the fuel distributor carefully.
9. Installation should follow the removal procedure in the
reverse order.
10. Check for fuel pressure and internal leakage by operating
the engine.
Fuel Pressure Test
1. Turn the ignition switch to "OFF" position.
2. Remove the fuel pressure test connector.
3. Connect the fuel pressure gauge to the fuel pressure test
connector.
4. Test the fuel pressure at idling by operating the engine.
Vacuum Hose Connected (bar)
Vacuum Hose Disconnected (bar)
5. Replace the pressure regulator diaphragm if out of the
specification.
3.2 - 3.6
3.7 - 4.2
