2C-12 FRONT SUSPENSION

AXLE VERTICAL ACCELERATION SENSOR (WHEEL G SENSOR)

1 Axle Vertical Acceleration Sensor (wheel G
sensor)
Removal & Installation Procedure
1. Disconnect extension wiring connector (2) from the axle
vertical acceleration sensor.
Notice
Installation of wiring connector should be as shown in the
right drawing.
2. Unscrew bolts (3) and remove the axle vertical acceleration
sensor (1).
Notice
When installing the sensor to the bracket, the sensor wiring
should be upward.
3. Installation should follow the removal procedure in the
reverse order.
2 Extension Wiring
3 Bolt (M6) ............................................. 20 - 30Nm
1 Actuator Connector
2 Axle Vertical Acceleration Sensor Connector
3 Front Hose Mounting Bracket
4 Frame Side Member
