SSANGYONG 1999 Musso Service Manual page 1123

5B-16 MANUAL TRANSMISSION
7. Remove the front and rear propeller shafts from the
transfercase.
Installation Notice
Tightening Torque
8. Support the transmission on an suitable jack.
Unscrew the center mounting nuts and each sides
mounting bolts and remove the cross member.
Installation Notice
Tightening Torque (1)
Tightening Torque (2)
9. Remove the transmission mounting bolts.
Installation Notice
Tightening Torque
10. Move the transmission jack backward careful and
disengage the transmission input shaft from the engine.
Remove the transmission.
11. Installation should follow the removal procedure in the
reverse order.
Front 81 - 89 Nm
Rear 70 - 90 Nm
21 - 35 Nm
62 - 93 Nm
77 - 87 Nm
