15. Install the C1 bias valve spring, valve, plug and 'O' ring.
Refer to figure 8.40.
16. Install the retaining pin. Refer to figure 8.39.
17. Install the converter release check ball and spring and the
feed ball. Refer to figures 8.41, 8.42 and 8.43.
Figure 8.40 - C1 Bias Valve
Figure 8.41 - Converter Relief Ball and Spring
Figure 8.42 - Peed Ball
Figure 8.42 - Feed Ball
AUTOMATIC TRANSMISSION 5A-115
