SSANGYONG 1999 Musso Service Manual page 770

Tools Required
617 589 09 21 00 Rl Sensor
617 589 10 21 00 Timing Tester
667 589 00 21 00 TDC Pulse Generator
Commercial Tools
Digital Tester
Test Procedure
1. Remove the screw plug (7) and seal (8) collect oil in a suitable
vessel.
2. Install the Rl sensor into the governor housing of injection
pump (1).
3. Connect the digital tester and TDC pulse sender unit
according to connection diagram.
4. Run the engine at idle speed and check the Rl value on the
digital tester
Rl value
Notice
If out of standard, adjust the start of delivery.
5. Stop the engine.
6. Remove the Rl sensor, digital tester and TDC pulse sender
unit.
7. Replace the seal and tighten the plug.
8. Check engine oil level and adjust if necessary.
Tightening Torque
Item
With Pulse Generator
Without Pulse Generator
Rl Sensor 617 589 10 21 00
ATDC 14° - 16°
30 Nm
OM600 ENGINE CONTROLS 1F3-41
Bosch, MOT 001.03
Hartmann & Braun, EOMT3
Bosch, ETD 019.00
Sun, DIT 9000
ALV, Diesel - Tester 875
Tools
