SSANGYONG 1999 Musso Service Manual page 686

Pin No.
21 Brake switch
22
-
23 -
24
-
25 -
26
-
27 Air conditioning clutch relay
28 -
29 -
30 -
31
Pedal potentiometer 1 ground
32 Pedal potentiometer 1 supply
33
Fuel pump relay
34 Tank purge valve
35
Engine fan(High)
36 -
37 CAN-Low
38 CAN-High
39 -
40
-
41 -
42
-
43 -
44
Air conditioning
45 Electronic traction signal
46 -
47
Pedal potentiometer 1 signal
48 Pedal potentiometer 2 signal
49
Brake light switch
50 Pedal potentiometer 2 ground
51
Pedal potentiometer 2 supply
52 Cruise accelerate/Set
53
Cruise resume
54 Cruise decelerate/Set
55 Cruise safety contact switch
56
-
57 Cruise off switch
58
Diagnostics(K-Line)
59 Vehicle speed signal
60
Engine speed signal
Description
M161 ENGINE CONTROLS 1F2-37
Abbreviation
BRS
-
-
-
-
-
KLIKU
-
-
-
GND
SP1+5V
KP
TEV
ML
-
CAN L
CAN H
-
-
-
-
KPI
KLIMA
ETS
-
SP1S
SP2S
BLS
GND
SP2+2.5V
S+B
WA
S-B
KSK
-
AUS
DIAG
V-SIG
TN-SIG
