SSANGYONG 1999 Musso Service Manual page 689

1F2-40 M161 ENGINE CONTROLS
Application
Pin No.
1 -
2 Starter motor TM.50
3 -
4 -
5 Electronic ground
6 -
7 Lambda probe 2 heating
8 -
9 Lambda probe 1 heating
10 Power ground TM.31
11 V-BATTERY TM.87
12 V-BATTERY TM.30
13 Immobilizer crypto read
14 Immobilizer crypto write
15 -
16 Lambda probe 1 ground
17 Lambda probe 1 signal
18 -
19 -
20 -
21 Brake switch
22 -
23 -
24 -
25 -
26 -
27 Air conditioning clutch relay
28 -
29 -
30 -
: Standard, : Option
Description
E23 ENG,
Abbreviation
5speed A/T
-
TM.50
-
-
GND
-
LSH2
-
LSH1
TM.31
TM.87
TM.30
WFS I/O
WFS O
-
GND
LS1
-
-
-
BRS
-
-
-
-
-
KLIKU
-
-
-
E23 ENG,
4speed A/T
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
-
-
- -
- -
