1B3-186 OM600 ENGINE MECHANICAL
Installation of Screw Plug
Notice
If steel ball leaks again, install the screw plug.
1. Remove the steel ball.
2. Tap thread into the bores of the oil gallery.
Notice
Front bore : M18 ´ 1.5, depth 10mm
Rear bore : M16 ´ 1.5, depth 14mm
3. Thoroughly clean the oil gallery.
4. Tighten the front plug (5) with seal (4).
Tightening Torque
5. Apply Loctite 241 and then tighten the rear plug (2).
Tightening Torque
50 Nm
50 Nm
