23. Holding the separator plate to the upper valve body to
prevent the check balls from falling out, install the upper
valve body on the lower valve body. Install all screws finger
tight then tighten the screws to specification in the
prescribed sequence. Refer to figure 8.58.
Figure 8.58 - Tightening Sequence Upper to Lower Valve Body
24. Install solenoids 1,2,3,4 and 6. Ensure the solenoid is firmly
secured by the retainer and that the screw is tightened to
specification.
25. Install solenoid 5. Ensure that the solenoid is pushed firmly
into the valve body by the retainer.
Notice
The wiring loom ground wire eyelet terminal is secured
beneath the solenoid retainer.
26. Install the line pressure relief valve, tapered end first, (refer
to figure 8.59), and the spring and disc. Secure with the
retaining pin.
AUTOMATIC TRANSMISSION 5A-123
Figure 8.59 - Line Pressure Relief Valve
