SSANGYONG 1999 Musso Service Manual page 880

3A-12 FRONT DRIVE AXLE
10. Remove the cotter pin and slotted nut and then remove
the steering knuckle arm and tie-rod.
Installation Notice
Tightening Torque
Replace the cotter pin with new one.
11. Remove the cotter pin and nut from the steering knuckle
arm and upper arm ball joint connection.
Installation Notice
Tightening Torque
Replace the cotter pin with new one.
12. Remove the cotter pin and nut from the steering knuckle
arm and lower and lower arm boll joint connection.
Installation Notice
Tightening Torque
13. Carefully remove the knuckle arm.
35 - 45 Nm
80 - 150 Nm
120 - 180 Nm
