SSANGYONG 1999 Musso Service Manual page 828

Self - Diagnosis List
Fault
Code
01 Vertical Acceleration Sensor
02 Lateral Acceleration Sensor
03 Wheel Acceleration Sensor
04 Front Step Motor
05 Rear Step Motor
06
Defects
ECU
SUSPENSION DIAGNOSIS 2A-13
Service Hint
1. Check sensor supply voltage
Condition - IGN ON
Standard value - voltage between pin 11 and 8 of ECU :
4.5 - 5.0V
2. Check sensor output voltage
Condition - IGN ON
Standard value - voltage between pin 20 and 11 of ECU
: 0.5 - 4.5V
3. Check the sensor.
4. Check circuit for open.
5. Check connection of other connectors.
1. Check sensor supply voltage
Condition - IGN ON
Standard value - voltage between pin 11 and 8 of ECU :
4.5 - 5.0V
2. Check sensor output voltage
Condition - IGN ON
Standard value - voltage between pin 10 and 11 of ECU
: 0.5 - 4.5V
3. Check the sensor.
4. Check circuit for open.
5. Check connection of other connectors.
1. Check sensor supply voltage
Condition - IGN ON
Standard value - voltage between pin 11, 8 and pin
7,11 of ECU : 4.5 - 5.0V
2. Check sensor output voltage
3. Check the sensor.
4. Check circuit for open.
5. Check connection of other connectors.
1. Check step motor supply voltage.
2. Check circuit for open.
3. Check connection of other connectors.
1. Check step motor supply voltage.
2. Check circuit for open.
3. Check connection of other connectors.
1. Check connectors of ECU.
2. Replace the ECU.
