Ecs (Ecu) - SSANGYONG 1999 Musso Service Manual

2C-14 FRONT SUSPENSION

ECS (ECU)

1 Electronically Controlled Suspension (ECU)
2 Connector
3 Bolts (2 pieces)
Removal & Installation Procedure
1. Disconnect each connectors from the console box and
remove the console box.
2. Disconnect ECU connector.
3. Unscrew 10mm x 2 bolts and remove ECS (ECU).
4. Installation should follow the removal procedure in the
reverse order.
4 Parking Brake Lever
5 Over Voltage Protection Relay
