Camber
1. Remove the free wheel hub.
2. Measure camber with a wheel alignment equipment.
Specification
3. If camber measurements are not within specification, adjust
it by increasing or decreasing the number of adjusting shims
(1) inserted between the upper arm shaft and cross bracket.
Camber Change
Adjusting Shims
1.6 Iarge
3.2 large
Notice
Difference between the left and right should be adjusted
within 30'.
Caster
1. Remove the free wheel hub.
2. Measure caster with a wheel alignment equipment and a
turning radius gauge.
Specification
0°±30'
Increasing 1 ea Decreasing 1 ea
+ 19'
+ 38'
2° 30' ± 30'
- 19'
- 38'
WHEEL ALIGNMENT 2B-7
