PPP-PT (Control LAN Packet/Port)
Table 404. TEST #1285 TDM Looparound Test — Continued
Error Test
Code Result
2000 ABORT
2012 ABORT
2100 ABORT
FAIL
PASS
SCOTCH Synchronous Looparound Test (#1275)
NOTE:
This test is destructive.
This test verifies the circuit in the data path of a ppp call. This test fails if the data
transmitted on the port does not match the data received in the looparound mode.
Failure of this test indicates a port hardware fault on the circuit pack.
This test aborts if calls are using the port, or if the PPP link associated with the
port is connected. To avoid this, first enter busyout data-module extension, or
busyout port UUCSSpp, or busyout link link#, which will cause all calls and
links using the port to be torn down.
555-233-119
Description/ Recommendation
Did not receive circuit pack test response within the allowable time period.
1. If this problem persists, reset the circuit pack (busyout board UUCSS,
reset board UUCSS, and release board UUCSS).
2. If the problem persists, replace the circuit pack.
Internal system error.
1. Retry the command at 1-minute intervals, up to 3 times.
2. Escalate if the problem persists.
Could not allocate the necessary system resources to run test.
1. Retry the command at 1-minute intervals, up to 5 times.
2. Escalate if the problem persists.
Received tones do not match transmitted tones.
1. Retry command at 1-minute intervals, up to 3 times.
2. If the problem persists, refer to TDM-BUS, Tone Generator, and Tone
Receiver repair procedures.
3. If the problem persists, reset the board (busyout board UUCSS, reset
board UUCSS, and release board UUCSS). Repeat the test.
4. If the problem persists, replace the circuit pack.
Port connections across the TDM bus function properly.
Continued on next page
