LUBRICATION
STRAINER SCREEN CLEANING
Separate the engine cases (Page lO-9).
Clean the strainer screen thoroughly,
Remove accumulated sediments from the engine
cases.
Install the strainer screen and assemble the engine
cases (Page 10-24).
LUBRICATION POINTS
~HONDA
~GL1200D'GL1200A
Oil STRAINER SCREEN
LUBRICATION POINT
LUBRICANT
REMARKS
Engine HONDA 4·STROKE Ollar AN
3.2l! (3.4 US
qt.
2.8 Imp qll
eQUIVALENT
Aller draInIng
API Service Cla$$,fical,on: Sf or SF
Final Drive Gear
Hypoid Gear Oil, SAE 80, API GL·5 130cm' 14.4 US OZ, 4.6
Imp ozl After draining
Front Fork
ATF (Automatic TransmISsion Fluid) 323cm'(10.9USoz.I1.4
Imo
01)
After draining
Steering Head Bearings
Steerinll Head Bearing Oust Seal
Suspension Ai, How Joint Q-rings
Brake Lever Pivot
Clutch Lever Pivot
Speedometer Gearbox
Swil'lg Arm Pivot Bearings and DU$! Seals
Final Driven Flange BoilS (Threadsl Multipurpose Grease
Front and Rear Wheel Bearings
Rear Wheel Bearing Dust Seal Lips
ThrOllle Grip Sliding Surface
Canter Stand Pivot
SIde Stand Pivol
Brake Pedal PiVOt
Seal Adju$l Lever Pivot
Seat Sliding Surfaces
Fool~ Pivol
Drive Shalt, Universal Joint Molybdenum Disulfide Grease
Dri~ Shalt Pinion Joint Splines and Oil Seal
Final Driven Flange Splines MOL YKOTEI!lBR2-PLUS manufac·
Final Driven Shall Oil Seal Up lured
by
Dow Corning, U.S.A.
Pinion Retainer O'i"ing
MULTIPURPOSE M·2 manufactured
Front Wheel Bearing Oust Seal Lips
by
MitSlJbistli Oil, Japan
Other lubticanu of equivalent qualily
Brake Caliper Pivot BoilS Sliding Surfaee Hi.Temperature Sill(:one Grease
Brake Caliper Slide Collau
Top Compartment Cover Pivol Light Weight Oil
Speedometer Cable
ThrOllle and Choke Cables
2-12
