Configuring and Monitoring the Switch Fabric Module
To configure the switch to use compact mode if you have only fabric-enabled modules installed, perform
this task:
Task
Configure the switch to use compact mode.
This example shows how to configure the switch to use compact mode:
Console> (enable) set system switchmode allow truncated
Console> (enable)

Switch Fabric Redundancy

No configuration is required for Switch Fabric Module redundancy. The module in slot 5 functions as
the primary module and a redundant Switch Fabric Module in slot 6 automatically takes over if the
primary module fails. A mixed redundant configuration with a WS-C6500-SFM and a
WS-X6500-SFM 2 is not supported.

Monitoring the Switch Fabric Module

This section describes how to monitor the Switch Fabric Module:
•
•
•
•
•
•
Enter all show commands supported by the Switch Fabric Module from the supervisor engine.
Note
Displaying the Module Information
To display the module information, perform this task in privileged mode:
Task
Display the module information.
This example shows how to display module information:
Console> (enable) show module
Mod Slot Ports Module-Type
--- ---- ----- ------------------------- ------------------- --- --------
1
4
Catalyst 6000 Family Software Configuration Guide—Releases 6.3 and 6.4
43-4
Displaying the Module Information, page 43-4
Displaying the Fabric Channel Counters, page 43-5
Displaying the Fabric Channel Switching Mode and Channel Status, page 43-5
Displaying the Fabric Channel Utilization, page 43-6
Displaying the Backplane Traffic and Fabric Channel Input and Output, page 43-7
Displaying Switching Mode Configuration, page 43-8
1 2 1000BaseX Supervisor
4 24 100BaseFX MM Ethernet
Chapter 43 Configuring the Switch Fabric Modules
Command
set system switchmode allow truncated
Command
show module mod
Model Sub Status
WS-X6K-SUP2-2GE yes ok
WS-X6224-MM-MT no ok
78-13315-02
