Chapter 8 Configuring Spanning Tree

Mapping VLANs to an MISTP Instance

When you are using MISTP-PVST+ or MISTP on a switch, you must map at least one VLAN to an
MISTP instance in order for MISTP-PVST+ or MISTP to be active. These sections describe how to
configure MISTP instances:
•
•
Note See
•
•
•
•
To use VLANs 1025–4094, you must enable MAC address reduction. See the
Note
Extended-Range VLANs" section on page 11-7
using extended-range VLANs.
To map a VLAN to an MISTP instance, perform this task in privileged mode:
Task
Step 1 Map a VLAN to an MISTP instance.
Step 2 Verify the VLAN is mapped.
This example shows how to map a VLAN to MISTP instance 1 and verify the mapping:
Console> (enable) set vlan 6 mistp-instance 1
Vlan 6 configuration successful
Console> (enable) show spantree mist-instance 1
Instance 1
Spanning tree mode
Spanning tree type
Spanning tree instance enabled
Designated Root
Designated Root Priority
Designated Root Cost
Designated Root Port
VLANs mapped:
Root Max Age
Bridge ID MAC ADDR
Bridge ID Priority
VLANs mapped:
Bridge Max Age 20 sec
Port
------------------------ ---- ------------- --------- ---- -------- ----------
78-13315-02
Determining MISTP Instances—VLAN Mapping Conflicts, page 8-30
Unmapping VLANs from an MISTP Instance, page 8-30
Chapter 11, "Configuring VLANs"
You can only map Ethernet VLANs to MISTP instances.
At least one VLAN in the instance must have an active port in order for MISTP-PVST+ or MISTP
to be active.
You can map as many Ethernet VLANs as you wish to an MISTP instance.
You cannot map a VLAN to more than one MISTP instance.
20 sec Hello Time 2 sec
Hello Time 2 sec
Inst Port-State
for details on using and configuring VLANs.
in Chapter 11, "Configuring VLANs"
Command
set vlan vlan mistp-instance instance
show spantree mistp-instance [instance] [active]
mod/port
MISTP-PVST+
ieee
00-d0-00-4c-18-00
49153 (root priority: 49152, sys ID ext: 1)
0
none
6
Forward Delay 15 sec
00-d0-00-4c-18-00
49153 (bridge priority: 49152, sys ID ext: 1)
6
Forward Delay 15 sec
Cost
Catalyst 6000 Family Software Configuration Guide—Releases 6.3 and 6.4
Using MISTP-PVST+ or MISTP
"Creating
for details on
Prio Portfast Channel_id
8-29
