Configuring the PVST+ Port Cost

You can configure the port cost of switch ports. The ports with lower port costs are more likely to be
chosen to forward frames. Assign lower numbers to ports that are attached to faster media (such as full
duplex) and higher numbers to ports that are attached to slower media. The possible cost is from 1 to
65535 when using the short method for calculating port cost and from 1 to 200000000 when using the
long method. The default cost differs for different media. For information about calculating port cost,
see the
To configure the PVST+ port cost for a port, perform this task in privileged mode:
Task
Step 1 Configure the PVST+ port cost for a switch
port.
Step 2 Verify the port cost setting.
When you enter the set channel cost command, it does not appear in the configuration file.
Note
The command causes a "set spantree portcost" entry to be created for each port in the
channel. See the
"Configuring EtherChannel,"
This example shows how to configure the PVST+ port cost on a port and verify the configuration:
Console> (enable) set spantree portcost 2/3 12
Spantree port 2/3 path cost set to 12.
Console> (enable) show spantree 2/3
VLAN 1
.
.
.
Port
------------------------ ---- ------------- --------- ---- -------- ----------
1/1
1/2
2/1
2/2
2/3
