Configuring Token Ring VLANs
This example shows how to create a new Token Ring TrBRF VLAN and verify the configuration:
Console> (enable) set vlan 999 name TrBRF_999 type trbrf bridge a
Vlan 999 configuration successful
Console> (enable) show vlan 999
VLAN Name
---- -------------------------------- --------- ------- ------------------------
999
VLAN Type
---- ----- ---------- ----- ------ ------ ------ ---- -------- ------ ------
999
VLAN AREHops STEHops Backup CRF
---- ------- ------- ----------
Console> (enable)
To modify the VLAN parameters on an existing Token Ring TrBRF VLAN, perform this task in
privileged mode:
Task
Step 1 Modify an existing Token Ring TrBRF-type
VLAN.
Step 2 Verify the VLAN configuration.

Creating or Modifying a Token Ring TrCRF VLAN

You must enable VTP version 2 before you create Token Ring VLANs. For information on enabling
Note
VTP version 2, see
To create a new Token Ring TrCRF VLAN, perform this task in privileged mode:
Task
Step 1 Create a new Token Ring TrCRF-type VLAN.
Step 2 Verify the VLAN configuration.
Note You must specify a ring number (either in hexadecimal or in decimal) and a parent TrBRF VLAN
when creating a new TrCRF.
Catalyst 6000 Family Software Configuration Guide—Releases 6.3 and 6.4
11-28
TrBRF_999
SAID MTU
trbrf 100999 4472
Chapter 10, "Configuring VTP."
Status IfIndex Mod/Ports, Vlans
active
Parent RingNo BrdgNo Stp
- - 0xa ibm
Command
set vlan vlan [name name] [state {active | suspend}]
[said said] [mtu mtu] [bridge bridgeber] [stp {ieee |
ibm}]
show vlan [vlan]
Command
set vlan vlan [name name] type trcrf [said said]
[mtu mtu] {ring hex_ringber | decring
decimal_ringber} parent vlan
show vlan [vlan]
Chapter 11 Configuring VLANs
BrdgMode Trans1 Trans2
- 0 0
