Chapter 41 Configuring QoS
Keyword
information-request
mask-reply
mask-request
mobile-redirect
net-redirect
net-tos-redirect
1. Matches all code values
Note ICMP ACEs with only a Layer 4 ICMP type parameter match all code values for that type value.
ICMP ACEs that do not include any Layer 4 ICMP type and code parameters match all ICMP traffic.
IP ACE Layer 4 IGMP Classification Criteria
You can create IGMP ACEs that match traffic containing specific IGMP messages by including an
IGMP type parameter (for more information, see the
page
host-query (1), host-report (2), dvmrp (3), pim (4), or trace (5).
QoS does not support Internet Group Management Protocol (IGMP) traffic when IGMP snooping is
Note
enabled. QoS supports IGMP classification using version 1 four-bit Type fields.
IGMP ACEs that do not include a Layer 4 IGMP type parameter match all IGMP traffic.
Note
IPX ACE Classification Criteria
You can create IPX ACEs that match specific IPX traffic by including these parameters (for more
information, see the
•
•
•
78-13315-02
41-40). You can specify the IGMP type numerically (0–255) or with these keywords:
"Creating or Modifying Named IPX ACLs" section on page
IPX source network (-1 matches any network number)
Protocol, which can be specified numerically (0–255) or with these keywords: any, ncp (17),
netbios (20), rip (1), sap (4), spx (5)
IPX ACEs support the following optional parameters:
IPX destination network (-1 matches any network number)
–
If you specify an IPX destination network, IPX ACEs support the following optional
–
parameters: an IPX destination network mask (-1 matches any network number), an IPX
destination node, and an IPX destination node mask
Type Code Keyword
15 0 time-exceeded
18 0 timestamp-reply
17 0 timestamp-request
32 0 traceroute
5 0 ttl-exceeded
5 2 unreachable
"IP ACEs for IGMP Traffic" section on
