RM0351
DMA must be initialized before setting the START bit. The end of transfer is managed
with the NBYTES counter.
•
In slave mode with NOSTRETCH=0, when all data are transferred using DMA, the
DMA must be initialized before the address match event, or in the ADDR interrupt
subroutine, before clearing the ADDR flag.
•
If SMBus is supported (see
managed with the NBYTES counter. Refer to
SMBus Master receiver on page
Note: If DMA is used for reception, the RXIE bit does not need to be enabled.
39.4.17 Debug mode
When the microcontroller enters debug mode (core halted), the SMBus timeout either
continues to work normally or stops, depending on the DBG_I2Cx_SMBUS_TIMEOUT
configuration bits in the DBG module.
39.5 I2C low-power modes
Mode
Sleep
Low-power run
Low-power sleep No effect. I2C interrupts cause the device to exit the Low-power sleep mode.
Stop 0 / Stop 1
Stop 2
Standby
Shutdown
1. I2C4 not available on STM32L475xx/476xx/486xxdevices.
39.6 I2C interrupts
The table below gives the list of I2C interrupt requests.
Section 39.3: I2C
1278.

Table 229. Effect of low-power modes on the I2C

No effect. I2C interrupts cause the device to exit the Sleep mode.
No effect.
The I2C registers content is kept. If WUPEN = 1 and I2C is clocked by HSI16: the
address recognition is functional. The I2C address match condition causes the
device to exit the Stop 0 and Stop 1 modes. If WUPEN=0: the I2C must be
disabled before entering Stop mode.
The I2C registers content is kept. The I2C1, I2C2 and I2C4
before entering Stop 2. If WUPEN=1 and I2C3 is clocked by HSI16: the I2C3
address recognition is functional. The I2C3 address match condition causes the
device to exit the Stop mode 2. If WUPEN=0: the I2C3 must be disabled before
entering Stop 2 mode.
The I2C peripheral is powered down and must be reinitialized after exiting
Standby or Shutdown mode.
DocID024597 Rev 5
Inter-integrated circuit (I2C) interface
implementation): the PEC transfer is
SMBus Slave receiver on page 1274
Description
and
(1)
must be disabled
1283/1830
