General-purpose timers (TIM15/TIM16/TIM17)
32.6.16 TIM16 option register 1 (TIM16_OR1)
Address offset: 0x50
Reset value: 0x0000
31 30 29
Res Res Res
15 14 13
Res Res Res
Bits 31:2 Reserved, must be kept at reset value.
Bits1:0 TI1_RMP[1:0]: Input capture 1 remap
00: TIM16 input capture 1 is connected to I/O
01: TIM16 input capture 1 is connected to LSI
10: TIM16 input capture 1 is connected to LSE
11: TIM16 input capture 1 is connected to RTC wakeup interrupt
32.6.17 TIM16 option register 2 (TIM16_OR2)
Address offset: 0x60
Reset value: 0x0000 0001
31 30 29
Res Res Res
15 14 13
Res Res Res
Bits 31:12 Reserved, must be kept at reset value.
Bit 11 BKCMP2P: BRK COMP2 input polarity
This bit selects the COMP2 input sensitivity. It must be programmed together with the BKP
polarity bit.
0: COMP2 input is active low
1: COMP2 input is active high
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
Bit 10 BKCMP1P: BRK COMP1 input polarity
This bit selects the COMP1 input sensitivity. It must be programmed together with the BKP
polarity bit.
0: COMP1 input is active low
1: COMP1 input is active high
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
1128/1830
