Low-power timer (LPTIM)
34.7.6
LPTIM compare register (LPTIM_CMP)
Address offset: 0x14
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 CMP: Compare value
CMP is the compare value used by the LPTIM.
The LPTIM_CMP register's content must only be modified when the LPTIM is enabled (ENABLE bit
is set to '1').
34.7.7
LPTIM autoreload register (LPTIM_ARR)
Address offset: 0x18
Reset value: 0x0000 0001
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 ARR: Auto reload value
ARR is the autoreload value for the LPTIM.
This value must be strictly greater than the CMP[15:0] value.
The LPTIM_ARR register's content must only be modified when the LPTIM is enabled (ENABLE bit
is set to '1').
