P04––V/F control
Function
Name
code
V/F curve setup
P04.00
of motor 1
Description
1: Enable
Limit the max. inertia compensation torque to
prevent inertia compensation torque from being
too large.
Setting range: 0.0–150.0% (rated motor torque)
Filter times of inertia compensation torque, used to
smooth inertia compensation torque.
Setting range: 0–10
Due to friction force, it is required to set certain
identification torque for the inertia identification to
be performed properly.
0.0–100.0% (rated motor torque)
0: No operation
1: Start identification
Automatic update will be performed after motor
parameter autotuning. In the closed-loop vector
control mode for synchronous motors, you can set
the value of this function code to P03.09.
Range: 0–65535
Note: Set the value to 0 if motor parameter
autotuning is not performed.
Automatic update will be performed after motor
parameter autotuning. In the closed-loop vector
control mode for synchronous motors, you can set
the value of this function code to P03.10.
Range: 0–65535
Note: Set the value to 0 if motor parameter
autotuning is not performed.
Description
This group of function code defines the V/F curve
of motor 1 to satisfy different load characteristics
needs.
0: Straight V/F curve; fit for constant-torque load
1: Multi-point V/F curve
2: Torque down V/F curve (1.3
-148-
Function parameter list
th
order)
Default
Modify
value
○
10.0%
○
7
○
10.0%
◎
0
●
0
●
0
Default
Modify
value
◎
0
