Goodrive350 series high-performance multifunction VFD
Function
Name
code
P05.07 Reserved
Polarity of input
P05.08
terminal
Description
42: Source of upper torque limit switches to
keypad
43: Position reference point input (only S6, S7 and
S8 are valid)
44: Spindle orientation disabled
45: Spindle zeroing/local positioning zeroing
46: Spindle zero position selection 1
47: Spindle zero position selection 2
48: Spindle scale division selection 1
49: Spindle scale division selection 2
50: Spindle scale division selection 3
51: Position control and speed control switch-over
terminal
52: Pulse input disabled
53: Clear position deviation cleared
54: Switch over position proportional gain
55: Enable cyclic positioning of digital position
positioning
56: Emergency stop
57: Motor over-temperature fault input
58: Enable rigid tapping
59: Switches to V/F control
60: Switches to FVC control
61: PID polarity switch-over
62: Reserved
63: Enable servo
64: Limit of forward run
65: Limit of reverse run
66: Zero out encoder counting
67: Pulse increase
68: Enable pulse superimposition
69: Pulse decrease
70: Electronic gear selection
71: Switch to master
72: Switch to slave
73–79: Reserved
0–65535
This function code is used to set the polarity of
input terminals.
-158-
Function parameter list
Default
Modify
value
●
0
○
0x000
