P22--Spindle Positioning - INVT Goodrive350 Series Operation Manual

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Pulse
P21.26 superposition
value
Pulse
P21.27 superposition
speed
Acceleration/dec
eleration time
P21.28
after disabling
pulse
Speed
feedforward filter
P21.29 time constant
(pulse string
speed mode)
Numerator of the
nd
P21.30 2 command
ratio
P21.31–
Reserved
P21.33
P22––Spindle positioning
Function
Name
code
Spindle
P22.00 positioning mode
selection
Description
Setting range: 0.000–60.000s
0–65535
0–6553.5
000.0–3000.0s
It is the filter time constant detected by pulse string
when the speed reference source is set to pulse
string (P0.06=12 or P0.07=12).
Setting range: 0–3200.0ms
1–65535
0–65535
Description
Bit0: Enable spindle positioning
0: Disable
1: Enable
Bit1: Select spindle positioning reference point
0: Z pulse input
1: S2/S3/S4 terminal input
Bit2: Search for reference point
0: Search the reference point only once
1: Search the reference point every time
Bit3: Enable reference point calibration
0: Disable
1: Enable
Bit4: Positioning mode selection 1
0: Set direction positioning
-221-
Function parameter list
Default
Modify
value
○
0
○
8.0
○
5.0s
○
10.0ms
○
1000
○
0
Default
Modify
value
○
0
