INVT Goodrive350 Series Operation Manual page 293

Goodrive350 series high-performance multifunction VFD
01 10
Continuous
VFD
address write
command
If the operation is successful, the following response is returned:
address
Example 2: Set "Acceleration time" of the VFD whose address is 01H to 10s, and "Deceleration time"
to 20s.
Function
Name
code
Acceleration
P00.11
time 1
Deceleration
P00.12
time 1
The address of P00.11 is 000B, 10s is 0064H in the hexadecimal form, and 20s is 00C8H in the
hexadecimal form.
The command transmitted by the master is as follows:
01 10
VFD Continuous
address
write
command
If the operation is successful, the following response is returned:
address
Note: In the preceding command description, spaces are added to a command just for explanatory
purposes. In practical applications, no space is required in the commands.
20 00 00 02
Parameter
Parameter
quantity
address
01 10
VFD Continuous
write
command
Acceleration time
accelerating from 0Hz to Max. output frequency
(P00.03).
Deceleration time is the time needed from
decelerating from Max. output frequency (P00.03)
to 0Hz.
Goodrive350 series VFD defines four groups of
acceleration and deceleration time, which can be
selected via multi-function digital input terminals
(P05 group). The acceleration/deceleration time of
the VFD is the first group by default.
Setting range of P00.11 and P00.12: 0.0–3600.0s
00 0B 00 02
Parameter
Parameter
address quantity
01 10
Continuous
VFD
write
command
04
Number of
bytes
20 00 00 02
Parameter
Parameter
address quantity
Description
is the time
04
Number of
bytes
00 0B 00 02
Parameter
Parameter
address quantity
-284-
00 01 03 E8
Froward
10 Hz
running
4A 08
CRC
Default
needed for Depends
on model
Depends
on model
00 64 00 C8
10s 20s
30 0A
CRC
Communication
3B 10
CRC
Modify
value
○
○
F2 55
CRC
