Goodrive350 series high-performance multifunction VFD
key, key or
the "parameter displayed in stop state" list or "parameter displayed in running state" list, the
parameter added will be at the end of the list; if the parameter is already in the "parameter displayed
in stop state" list or "parameter displayed in running state" list, the addition operation will be invalid. If
key or
return to monitoring parameter list menu.
Part of the monitoring parameters in P07 HMI group can be added to the "parameter displayed in stop
state" list or "parameter displayed in running state" list; All the parameters in P17, P18 and P19 group
can be added to the "parameter displayed in stop state" list or "parameter displayed in running state"
list.
Up to 16 monitoring parameters can be added to the "parameter displayed in stop state" list; and up
to 32 monitoring parameters can be added to the "parameter displayed in running state" list.

5.4.4 Add parameter to common parameter setup list

In fourth-level menu of "parameter setup" menu, the parameter in the list can be added to the
"common parameter setup" list as shown below.
16:02:35 Forward
P01.00：Running mode of start
P01.01：Starting frequency of direct start
P01.02：Hold-up time of starting frequency
P01.03：Brake current before start
P01.04：Brake time before start
P01.05：Acceleration/deceleration mode selection
Return
Add key to enter addition interface, and press
the addition operation. If this parameter is not included in the original "common parameter setup" list,
the newly-added parameter will be at the end of the list; if this parameter is already in the "common
parameter setup" list, the addition operation will be invalid. If
without selecting addition operation, it will return to parameter setup list menu.
All the function code groups under parameter setup sub-menu can be added to "common parameter
setup" list. Up to 64 function codes can be added to the "common parameter setup" list.

5.4.5 Parameter selection edit interface

In the fourth-level menu of "parameter setup" menu, press
parameter selection edit interface. After entering edit interface, current value will be highlighted. Press
key and key to edit current parameter value, and the corresponding parameter item of
current value will be highlighted automatically. After parameter selection is done, press
key to save the selected parameter and return to the previous menu. In parameter selection edit
interface, press
key to confirm the addition operation. If this parameter is not included in
key is pressed without selecting addition peration in "Addition" interface, it will
Local Ready 01：GD350
Add
Select
Figure 5.14 Add parameter diagram 2
key to maintain the parameter value and return to the previous menu.
16:02:35
Forward
Ensure to add to common
parameter setup?
Return
key,
key,
-43-
Basic operation instructions
Local Ready 01：GD350
Homepage
Confirm
key or key to confirm
key or key is pressed
key or key to enter
key or
