Goodrive350 series high-performance multifunction VFD
LED
(Slave ready indicator)
LED5
(Maintenance state
indicator)
LED6/7
(Network port state
indicator)
LED8/9
(Network port
communication
indicator)
Electrical connection:
The PROFINET communication card adopts a standard RJ45 interface, which can be used in a linear
network topology and a star network topology. The linear network topology electrical connection
diagram is shown below.
Master
device
Note: For the star network topology, you need to prepare PROFINET switches.
The star network topology electrical connection diagram is shown below:
Master
device
Color State
Blinking
Off
Green
On
Green
Off
On
Green
Off
Slave device 1 Slave device 2
RJ45 RJ45
RJ45
Slave device 1 Slave device 2
RJ45 RJ45 RJ45
Switch
-308-
Description
TPS-1 waits for MCU initialization.
TPS-1 protocol stack does not start.
Manufacturer-specific - depending on
the characteristics of the device.
PROFINET communication card and
PC/PLC have been connected with a
network cable.
PROFINET communication card and
PC/PLC have not been connected yet.
PROFINET communication card and
PC/PLC are communicating.
PROFINET communication card and
PC/PLC are not yet communicating.
Slave device n
RJ45
RJ45
Slave device n
RJ45 RJ45
Extension cards
RJ45
RJ45
