GD200A series VFD
Function
Name
code
Pre-exciting
P03.25
time
Weak magnetic
P03.26 proportional
gain
Vector control
P03.27
speed
Compensation
P03.28 coefficient of
static friction
Compensation
P03.29 coefficient of
dynamic friction

P04 Group SVPWM control

Function
Name
code
Motor 1 V/F
P04.00
curve setting
Description
Reactivate the motor when the VFD starts up.
Build up a magnetic field inside the VFD to
improve the torque performance during the
starting process.
The setting time: 0.000–10.000s
0–8000
Note: P03.24–P03.26
0: Display the actual value
1: Display the setting value
0.0–100.0%
Adjust P03.28 to compensate the coefficient of
static friction. Only valid when setting in 1Hz.
0.0–100.0%
Adjust P03.29 to compensate the coefficient of
static friction. Only valid when setting in 1Hz.
Description
These function codes define the V/F curve of
Goodrive200A motor 1, and meet the need of
different loads.
0: Straight line V/F curve; applying to the constant
torque load
1: Multi-dots V/F curve
th
2: 1.3 power low torque V/F curve
th
3: 1.7 power low torque V/F curve
th
4: 2.0 power low torque V/F curve
Curves 2–4 apply to the torque loads such as fans
and water pumps. Users can adjust according to
the features of the loads to achieve a best
energy-saving effect.
5: Customized V/F (V/F separation); in this mode,
V can be separated from f and f can be adjusted
through the frequency reference channel set by
P00.06 or the voltage reference channel set by
P04.27 to change the feature of the curve.
Note: V in the below picture is the motor rated
b
voltage and f is the motor rated frequency.
b
-52-
are invalid for vector mode.
Function parameters
Default
Modify
value
○
0.300s
○
1000
○
0
○
0.0%
○
0.0%
Default
Modify
value
◎
0
