INVT Goodrive350 Series Operation Manual page 153

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Source of upper
limit frequency
P03.14 setup of forward
rotation in torque
control
Source of upper
limit frequency
P03.15 setup of reverse
rotation in torque
control
Keypad limit
value of upper
P03.16 limit frequency of
forward rotation
in torque control
Max. output
P03.17
frequency
Source of upper
P03.18
limit setup of the
Description
0: Keypad (P03.16)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: Modbus communication (the same as above)
7: PROFIBUS /CANopen/ DeviceNet
communication (the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCAT/PROFINET communication
11: PLC
12: Reserved
0: Keypad (P03.17)
1: AI1 (100% corresponds to max. frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as above)
5: Multi-step (the same as above)
6: Modbus communication (the same as above)
7: PROFIBUS /CANopen/ DeviceNet
communication (the same as above)
8: Ethernet communication (the same as above)
9: Pulse frequency HDIB (the same as above)
10: EtherCAT/PROFINET communication
11: PLC
12: Reserved
Note: For sources 1–11, 100% relative to the max.
frequency
This function code is used to set frequency limit.
100% corresponds to the max. frequency. P03.16
sets the value when P03.14=1; P03.17 sets the
value when P03.15=1.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
0: Keypad (P03.20)
1: AI1
-144-
Function parameter list
Default
Modify
value
○
0
○
0
○
50.00Hz
○
50.00Hz
○
0
