Goodrive350 series high-performance multifunction VFD
Function
code
Output terminal polarity
P06.05
Y switch-on delay
P06.06
Y switch-off delay
P06.07
HDO switch-on delay
P06.08
HDO switch-off delay
P06.09
Relay RO1 switch-on
P06.10
Relay RO1 switch-off
P06.11
Relay RO2 switch-on
P06.12
Relay RO2 switch-off
P06.13
Output terminal state of
P07.40
Name
selection
delay
delay
delay
delay
present fault
Description
34: Virtual terminal output of
EtherCAT/PROFINET communication
35: Reserved
36: Speed/position control switch-over
completed
37: Any frequency reached
38–40: Reserved
41: C_Y1 from PLC (You need to set P27.00
to 1.)
42: C_Y2 from PLC (You need to set P27.00
to 1.)
43: C_HDO from PLC (You need to set
P27.00 to 1.)
44: C_RO1 from PLC (You need to set
P27.00 to 1.)
45: C_RO2 from PLC (You need to set
P27.00 to 1.)
46: C_RO3 from PLC (You need to set
P27.00 to 1.)
47: C_RO4 from PLC (You need to set
P27.00 to 1.)
48–63: Reserved
0x00–0x0F
0.000–50.000s
0.000–50.000s
0.000–50.000s (valid only when P06.00=1)
0.000–50.000s (valid only when P06.00=1)
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
/
