A.5 Programmable extension card EC-PC501-00
The terminals are arranged as follows:
SW1 is the start/stop switch of the programmable extension card. CN6 is the program download port,
and you can connect to a computer by using a standard USB cable. COM and CME are shorted
through J1 before delivery.
PY1 PY2
COM PS1
PW +24V
Indicator definition:
Name
Digital input 1
Digital input 2
Digital input 3
Digital input 4
Digital output
NO contact of
RO3A
relay 3
NC contact of
RO3B
relay 3
Common contact
RO3C
of relay 3
NO contact of
RO4A
relay 4
Common contact
RO4C
of relay 4
CME COM
PS2 PS3
PS4 PS5
Function description
3. Deviation ±0.5%; input of 5 V or 10 mA or
higher at the temperature of 25° C
1. Internal impedance: 3.3 kΩ
2. Power input range: 12–30 V
3. Bidirectional input terminal
4. Max. input frequency: 1 kHz
1. Switch capacity: 50 mA/30 V
2. Output frequency range: 0–1 kHz
3. The terminals CME and COM are
shorted through J3 before delivery.
1. Contact capacity: 3A/AC 250 V, 1 A/DC
30 V
2. Do not use them as high-frequency
digital outputs.
PRO1A
PS6
