Goodrive350 series high-performance multifunction VFD
Function
code
P03.12 Torque set by keypad
P03.13 Torque reference filter time 0.000–10.000s
Source of upper limit
P03.14 frequency setup of forward
rotation in torque control
Source of upper limit
P03.15 frequency setup of reverse
rotation in torque control
Keypad limit value of upper
P03.16 limit frequency of forward
rotation in torque control
Keypad limit value of upper
P03.17
limit frequency of reverse
Name
communication
9: Ethernet communication
10: Pulse frequency HDIB
11: EtherCAT/PROFINET communication
12: PLC
Note: For setting sources 2–6 and 10,
100% corresponds to three times the rated
motor current.
-300.0%–300.0% (rated motor current)
0: Keypad (P03.16)
1: AI1 (100% corresponds to max.
frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDIA (the same as
above)
5: Multi-step (the same as above)
6: Modbus communication (the same as
above)
7: PROFIBUS /CANopen/ DeviceNet
communication (the same as above)
8: Ethernet communication (the same as
above)
9: Pulse frequency HDIB (the same as
above)
10: EtherCAT/PROFINET communication
11: PLC
12: Reserved
Note: For sources 1–11, 100% relative to
the max. frequency
0: Keypad (P03.17)
1–11: the same as P03.14
Value range: 0.00 Hz–P00.03 (Max. output
frequency)
Description
-56-
Basic operation instructions
Default
value
50.0%
0.010s
0
0
50.00Hz
50.00Hz
