INVT Goodrive350 Series Operation Manual page 110

Goodrive350 series high-performance multifunction VFD
Set
value
0
1
2 In forward running
3 In reverse running
4
5
Frequency level detection
6
Frequency level detection
7
8 Frequency reached
9 Running in zero speed
Reach upper limit
10
Reach lower limit
11
12 Ready to run
13 In pre-exciting
14 Overload pre-alarm
15 Underload pre-alarm
Simple PLC state
16
Simple PLC cycle
17
Virtual terminal output of
23
Modbus communication
Function
Invalid
In running
In jogging
VFD fault
FDT1
FDT2
frequency
frequency
completed
completed
Output terminal has no function
Output ON signal when there is frequency output during
running
Output ON signal when there is frequency output during
forward running
Output ON signal when there is frequency output during
reverse running
Output ON signal when there is frequency output during
jogging
Output ON signal when VFD fault occurred
Refer to P08.32 and P08.33
Refer to P08.34 and P08.35
Refer to P08.36
Output ON signal when the VFD output frequency and
reference frequency are both zero.
Output ON signal when the running frequency reaches
upper limit frequency
Output ON signal when the running frequency reached
lower limit frequency
Main circuit and control circuit powers are established,
the protection functions do not act; when the VFD is
ready to run, output ON signal.
Output ON signal during pre-exciting of the VFD
Output ON signal after the pre-alarm time elapsed based
on the pre-alarm threshold; see P11.08–P11.10 for
details.
Output ON signal after the pre-alarm time elapsed based
on the pre-alarm threshold; see P11.11–P11.12 for
details.
Output signal when current stage of simple PLC is
completed
Output signal when a single cycle of simple PLC
operation is completed
Output corresponding signal based on the set value of
Modbus; output ON signal when it is set to 1, output OFF
signal when it is set to 0
-101-
Basic operation instructions
Description
