Goodrive350 series high-performance multifunction VFD
Code Name
Invalid data
02H
address
03H Invalid data bit
Operation
04H
failure
Password
05H
error
Data frame
06H
error
Parameter
07H
read-only
Parameter
cannot be
08H
modified in
running
Password
09H
protection
When returning a response, the device uses a function code domain and fault address to indicate
whether it is a normal response (no error) or exception response (some errors occur). In a normal
response, the device returns the corresponding function code and data address or sub-function code.
In an exception response, the device returns a code that is equal to a normal code, but the first bit is
logic 1.
For example, if the master device transmits a request message to a slave device for reading a group
of function code address data, the code is generated as follows:
0 0 0 0 0 0 1 1 (03H in the hexadecimal form)
For a normal response, the same code is returned.
For an exception response, the following code is returned:
1 0 0 0 0 0 1 1 (83H in the hexadecimal form)
In addition to the modification of the code, the slave returns a byte of exception code that describes
For the VFD, the data address in the request of the upper
computer is not allowed. In particular, the combination of the
register address and the number of the to-be-transmitted bytes is
invalid.
The received data domain contains a value that is not allowed. The
value indicates the error of the remaining structure in the combined
request.
Note: It does not mean that the data item submitted for storage in
the register includes a value unexpected by the program.
The parameter is set to an invalid value in the write operation. For
example, a function input terminal cannot be set repeatedly.
The password entered in the password verification address is
different from that set in P07.00.
The length of the data frame transmitted by the upper computer is
incorrect, or in the RTU format, the value of the CRC check bit is
inconsistent with the CRC value calculated by the lower computer
The parameter to be modified in the write operation of the upper
computer is a read-only parameter.
The parameter to be modified in the write operation of the upper
computer cannot be modified during the running of the VFD.
A user password is set, and the upper computer does not provide
the password to unlock the system when performing a read or write
operation. The error of "system locked" is reported.
-280-
Definition
Communication
