INVT Goodrive350 Series Operation Manual page 180

Goodrive350 series high-performance multifunction VFD
Function
Name
code
display
coefficient
Temperature of
P07.11 rectifier bridge
module
Temperature of
P07.12
inverter module
Software version
P07.13
of control board
Accumulated
P07.14
running time
High bit of VFD
P07.15 power
consumption
Low bit of VFD
P07.16 power
consumption
P07.17 Reserved
Rated power of
P07.18
VFD
Rated voltage of
P07.19
VFD
Rated current of
P07.20
VFD
P07.21 Factory barcode 1 0x0000–0xFFFF
P07.22 Factory barcode 2 0x0000–0xFFFF
P07.23 Factory barcode 3 0x0000–0xFFFF
P07.24 Factory barcode 4 0x0000–0xFFFF
P07.25 Factory barcode 5 0x0000–0xFFFF
P07.26 Factory barcode 6 0x0000–0xFFFF
Type of present
P07.27
fault
Type of the last
P07.28
fault
Type of the
P07.29
2nd-last fault
Type of the
P07.30
3rd-last fault
Description
Linear speed=mechanical speed×P07.10
-20.0–120.0° C
-20.0–120.0° C
1.00–655.35
0–65535h
Display the power consumption of the VFD.
VFD power consumption=P07.15×1000+P07.16
Setting range of P07.15: 0–65535 kWh (×1000)
Setting range of P07.16: 0.0–999.9 kWh
0.4–3000.0kW
50–1200V
0.1–6000.0A
0: No fault
1: Inverter unit U phase protection (OUt1)
2: Inverter unit V phase protection (OUt2)
3: Inverter unit W phase protection (OUt3)
4: Overcurrent during acceleration (OC1)
5: Overcurrent during deceleration (OC2)
6: Overcurrent during constant speed (OC3)
7: Overvoltage during acceleration (OV1)
-171-
Function parameter list
Default
Modify
value
●
/
●
/
●
/
●
/
●
/
●
/
/
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
●
/
