A.7.3 Resolver PG card––EC-PG504-00
PE AO+
GND AO-
Indicator definition:
Indicator No.
LED1
LED2
LED3
The EC-PG504-00 extension card can be used in combination with a resolver of excitation voltage 7
Vrms. It is user-friendly, adopting spring terminals.
EC-PG504-00 terminal function description:
Symbol
SI+
SI-
CO+
CO-
EX+
EX-
A2+
BO+ ZO+ EX+
BO- ZO- EX-
Definition
State indicator
Disconnection indicator
Power indicator
Name
Encoder signal input
Encoder excitation
signal
Pulse setting
SI+ CO+ A2+
SI- CO- A2-
This indicator is on when the extension card is
establishing a connection with the control board; it
blinks periodically after the extension card is
properly connected to the control board (the
period is 1s, on for 0.5s, and off for the other
0.5s); and it is off when the extension card is
disconnected from the control board.
This indicator is off when the encoder is
disconnected; it is on when the encoder signals
are normal; and it blinks when the encoder signals
are not stable.
This indicator is on after the control board feeds
power to the PG card.
Function description
Recommended resolver transformation ratio: 0.5
1. Factory setting of excitation: 10 kHz
2. Supporting resolvers with an excitation voltage
of 7 Vrms
1. Differential input of 5 V
