Goodrive350 series high-performance multifunction VFD

3.6 Rated value

3.6.1 AC 3PH 380V(-15%)–440V(+10%) rated value
Product model
GD350-1R5G-4
GD350-2R2G-4
GD350-004G-4
GD350-5R5G-4
GD350-7R5G-4
GD350-011G-4
GD350-015G-4
GD350-018G-4
GD350-022G-4
GD350-030G-4
GD350-037G-4
GD350-045G-4
GD350-055G-4
GD350-075G-4
GD350-090G-4
GD350-110G-4
GD350-132G-4
GD350-160G-4
GD350-185G-4
GD350-200G-4
GD350-220G-4
GD350-250G-4
GD350-280G-4
GD350-315G-4
GD350-355G-4
GD350-400G-4
GD350-450G-4
GD350-500G-4
Note:

The input current of the 1.5–500kW VFD models is measured in cases where the input voltage
is 380V without additional reactors.

The rated output current is the output current when the output voltage is 380V.

Within allowable input voltage range, the output current/power cannot exceed the rated output
current/power.
Output power (kW)
1.5
2.2
4
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
355
400
450
500
Input current (A)
5.0
5.8
13.5
19.5
25
32
40
47
51
70
80
98
128
139
168
201
265
310
345
385
430
460
500
580
625
715
840
890
-12-
Product overview
Output current (A)
3.7
5
9.5
14
18.5
25
32
38
45
60
75
92
115
150
180
215
260
305
340
380
425
480
530
600
650
720
820
860
