Goodrive350 series high-performance multifunction VFD
W1
H1
Figure C.15 Wall-mounting diagram for 660V 160–220kW models
W1
H1
Figure C.16 Wall-mounting diagram for 660V 250–355kW models
Table C.4 Wall-mounting dimensions of 660V VFD models (unit: mm)
VFD model
22kW–45kW
55kW–132kW
160kW–220kW
250kW–355kW
W1 W2
270 130
325 200
500 180
680 230
D1
D1
H2
H1 H2
555 540
680 661
870 850
960 926
-334-
Dimension drawings
W2
6- ø11.0
H2
W2 W2
Installation
D1
hole
325 Ø 7
365 Ø 9.5
360 Ø 11
380 Ø 13
W2
6- ø13.0
Fixing
screw
M6
M8
M10
M12
