Goodrive350 series high-performance multifunction VFD
Function
code
P06.00 HDO output type
P06.01 Y1 output selection
P06.02 HDO output selection
Relay RO1 output
P06.03
Relay RO2 output
P06.04
Name
0: Open collector high-speed pulse output
1: Open collector output
0: Invalid
1: In running
2: In forward running
3: In reverse running
selection
4: In jogging
5: VFD fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Running in zero speed
10: Reach upper limit frequency
11: Reach lower limit frequency
12: Ready to run
13: In pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
16: Simple PLC stage completed
17: Simple PLC cycle completed
18: Reach set counting value
19: Reach designated counting value
20: External fault is valid
selection
21: Reserved
22: Reach running time
23: Virtual terminal output of Modbus
communication
24: Virtual terminal output of
POROFIBUS/CANopen communication
25: Virtual terminal output of Ethernet
communication
26: DC bus voltage established
27: Z pulse output
28: During pulse superposition
29: STO action
30: Positioning completed
31: Spindle zeroing completed
32: Spindle scale-division completed
33: In speed limit
Description
-103-
Basic operation instructions
Default
value
0
0
0
1
5
