Set vector control parameters
Set the motor parameters of
P02.01–P02.05 as per the
motor nameplate
If the motor rotates in wrong direction, power off
and exchange the motor wires of any two phases,
Complete parameter rotary
autotuning
SVC 1 (P00.00=0)
in P03 group
Start
Power up after confirming the
wiring is correct
Restore to default value
(P00.18=1)
Set the motor parameters of
P02.15–P02.19 as per the
motor nameplate
Press QUICK/JOG to jog
and power on again
Set autotuning mode
(P00.15)
Complete parameter static
autotuning
Start autotuning after pressing
RUN key, and stop after
autotuning is done
Set running command channel
(P00.01, P00.02)
Set running frequency
Set speed running control
mode (P00.00)
SVC 2 (P00.00=1)
Set vector control parameters
in P03 group
Set start/stop control
parameters in P01 group
Run after running command
Stop after stop command
End
-50-
Basic operation instructions
Partial parameter rotary
autotuning
SVPWM control mode
(P00.00=2)
Set V/F parameters in P04
group
