Goodrive350 series high-performance multifunction VFD
Function
Name
code
detection time
Automatic
frequency-reducti
P11.16
on during voltage
drop
Proportional
coefficient of
P11.17 voltage regulator
during
undervoltage stall
Integral
coefficient of
P11.18 voltage regulator
during
undervoltage stall
Proportional
coefficient of
P11.19 current regulator
during
undervoltage stall
Integral
coefficient of
P11.20 current regulator
during
undervoltage stall
Proportional
P11.21 coefficient of
voltage regulator
Description
detection time.
Note: Speed deviation protection is invalid
when P11.15 is set to 0.0.
Speed
Actual detection
value
Set detection
value
t1<t2, so the VFD continues running
t2=P11.15
Setting range: 0.0–10.0s
0–1
0: Invalid
1: Valid
This parameter is used to set the proportional
coefficient of the bus voltage regulator during
undervoltage stall.
Setting range: 0–1000
This parameter is used to set the integral
coefficient of the bus voltage regulator during
undervoltage stall.
Setting range: 0–1000
This parameter is used to set the proportional
coefficient of the active current regulator during
undervoltage stall.
Setting range: 0–1000
This parameter is used to set the integral
coefficient of the active current regulator during
undervoltage stall.
Setting range: 0–2000
This parameter is used to set the proportional
coefficient of the bus voltage regulator during
overvoltage stall.
-194-
t1 Time t
t2
Running Fault output dEu
Function parameter list
Default
Modify
value
○
0
○
100
○
40
○
25
○
150
○
60
