5.4.2 List edit

The monitoring items displayed in the parameter list of stop state can be added as needed (through
the menu of the function code in state check group), and the list can also be edited such as "shift up",
"shift down" and "delete from the list". The edit function is shown in the following.
16:02:35
Forward Local Ready
Parameter displayed in stop state
Parameter displayed in running state
Return Homepage
Press key to enter edit interface, select the operation needed, and press
key or key to confirm the edit operation and return to the previous menu (parameter list), the
returned list is the list edited. If
Operate the storage area 1:
BACKUP01
/
Operate the storage area 2:
BACKUP012
Operate the storage area 3:
BACKUP03
Restore function parameter
to default value
/ /
16:02:35
01: GD350
P17.00：Set frequency
P17.11：DC bus voltage
P17.12：Digital input terminal state
P17.13：Digital output terminal state
P17.23：PID reference value
P17.24：PID feedback value
Return
Select
Figure 5.10 List edit diagram 1
key or
Third-level
Forward Local Ready 01: GD350
Edit
Confirm
key is pressed in edit interface wihouth selecting
