INVT Goodrive350 Series Operation Manual page 254

Goodrive350 series high-performance multifunction VFD
Fault
Fault type
code
Communication
timeout occurred to
C3-Er
the extension card in
card slot 3
Profibus card
E-DP communication
timeout fault
Ethernet card
E-NET communication
timeout fault
CANopen card
E-CAN communication
timeout fault
PROFINET card
E-PN communication
timeout fault
EtherCAT card
E-CAT communication
timeout fault
BACNet card
E-BAC communication
timeout fault
Possible cause
There is no data
transmission in interfaces of
card slot 3
There is no data
transmission between the
communication card and the
host computer (or PLC)
There is no data
transmission between the
communication card and the
host computer
There is no data
transmission between the
communication card and the
host computer (or PLC)
There is no data
transmission between the
communication card and the
host computer (or PLC)
There is no data
transmission between the
communication card and the
host computer (or PLC)
There is no data
transmission between the
communication card and the
host computer (or PLC)
-245-
Troubleshooting
Corrective measures
Check whether the insertion
port is damaged, if yes, replace
the insertion port after power
down
Confirm whether the extension
card inserted can be supported;
Stabilize the extension card
interfaces after power down,
and confirm whether fault still
occurs at next power-on;
Check whether the insertion
port is damaged, if yes, replace
the insertion port after power
down
Check whether the
communication card wiring is
loose or dropped
Check whether the
communication card wiring is
loose or dropped
Check whether the
communication card wiring is
loose or dropped
Check whether the
communication card wiring is
loose or dropped
Check whether the
communication card wiring is
loose or dropped
Check whether the
communication card wiring is
loose or dropped
