Goodrive350 series high-performance multifunction VFD
Function
VFD state word 2
VFD fault code
VFD identification
code
Running frequency
Set frequency
Bus voltage
Output voltage
Output current
Rotating speed
Output power
Output torque
Closed-loop setting
Closed-loop feedback
Input state
Output state
Analog input 1
Analog input 2
Analog input 3
Analog input 4
Read input of
Address
Bit0: =0: Not ready to run =1: Ready to run
Bi1–2: =00: Motor 1
=10: Motor 3
Bit3: =0: Asynchronous machine =1:
Synchronous machine
Bit4: =0: No overload alarm =1: Overload alarm
Bit5–Bit6: =00: Keypad-based control
2101H Terminal-based control
=10: Communication-based control
Bit7: Reserved
Bit8: =0: Speed control =1: Torque control
Bit9: =0: Non-position control =1: Position control
Bit10–bit11: =0: Vector 0 =1: Vector 1
2102H See the description of fault types.
2103H GD350-----0x01A0
3000H 0–Fmax (unit: 0.01Hz)
3001H 0–Fmax (unit: 0.01Hz)
3002H 0.0–2000.0 V (unit: 0.1V)
3003H 0–1200V (unit: 1V)
3004H 0.0–3000.0A (unit: 0.1A)
3005H 0–65535 (unit: 1RPM)
3006H -300.0–+300.0% (unit: 0.1%)
3007H -250.0–+250.0% (unit: 0.1%)
3008H -100.0–+100.0% (unit: 0.1%)
3009H -100.0–+100.0% (unit: 0.1%)
000–3F
300AH Corresponding to the local
HDIB/ HDIA/S4/S3/S2/S1
000–0F
300BH Corresponding to the local
RO2/RO1/HDO/Y1
300CH 0.00–10.00V (unit: 0.01V)
300DH 0.00–10.00V (unit: 0.01V)
300EH -10.00–10.00V (unit: 0.01V)
300FH
3010H 0.00–50.00kHz (unit: 0.01Hz)
Data description
=01: Motor 2
=11: Motor 4
=2: Closed-loop vector
=3: Space voltage vector
-277-
Communication
R/W
=01:
Compatible
with CHF100A
and CHV100
communication
addresses
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
