INVT Goodrive350 Series Operation Manual page 350

Goodrive350 series high-performance multifunction VFD
VFD model
GD350-004G-4
GD350-5R5G-4
GD350-7R5G-4
GD350-011G-4
GD350-015G-4
GD350-018G-4
GD350-022G-4
GD350-030G-4
GD350-037G-4
GD350-045G-4
GD350-055G-4
GD350-075G-4
GD350-090G-4
GD350-110GP-4
GD350-132G-4
GD350-160G -4
GD350-185G-4
GD350-200G-4
GD350-220G-4
GD350-250G-4
GD350-280G-4
GD350-315G-4
GD350-355G-4
GD350-400G-4
GD350-450G-4
GD350-500G-4
Note:

Cables of the sizes recommended for the main circuit can be used in scenarios where the
ambient temperature is lower than 40° C, the wiring distance is shorter than 100 m, and the
current is the rated current.

The terminals P1, (+), PB, and (-) are used to connect to DC reactors and braking accessories.
VFD model
GD350-022G-6
GD350-030G-6
GD350-037G-6
GD350-045G-6
GD350-055G-6
GD350-075G-6
GD350-090G-6
GD350-110G-6
GD350-132G-6
GD350-160G -6
GD350-185G-6
Recommended cable size (mm² )
R, S, T
PE
U, V, W
1.5 1.5
1.5 1.5
2.5 2.5
4 4
6 6
10 10
10 10
16 16
25 16
25 16
35 16
50 25
70 35
95 50
95 50
150 70
185 95
185 95
2×95 95
2×95 95
2×150 150
2×150 150
2×185 185
3×150 2×120
3×185 2×150
3×185 2×150
Table D.2 AC 3PH 520V(-15%)–690V(+10%)
Recommended cable size (mm² )
R, S, T
PE
U, V, W
4 4
6 6
6 6
10 10
16 16
16 16
16 16
25 16
35 16
50 25
70 35
-341-
Optional peripheral accessories
PB, (+),
P1, (+)
(-)
1.5 1.5
1.5 1.5
2.5 2.5
4 4
6 6
10 10
10 10
16 16
25 25
25 25
35 35
50 50
70 70
95 95
95 95
150 150
185 185
185 185
2×95 2×95
2×95 2×95
2×150 2×150
2×150 2×150
2×185 2×185
3×150 3×150
3×185 3×185
3×185 3×185
PB, (+),
P1, (+)
(-)
4 4
6 6
6 6
10 10
16 16
16 16
16 16
25 25
35 35
50 50
70 70
Screw
Terminal Fastening
screw torque (Nm)
M4 1.2–1.5
M5 2–2.5
M5 2–2.5
M5 2–2.5
M5 2–2.5
M6 4–6
M6 4–6
M8 9–11
M8 9–11
M8 9–11
M10 18–23
M10 18–23
M10 18–23
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
M12 31–40
Screw
Terminal Fastening
screw torque (Nm)
M8 9–11
M8 9–11
M8 9–11
M8 9–11
M10 18–23
M10 18–23
M10 18–23
M10 18–23
M10 18–23
M12 31–40
M12 31–40
