8.3 Cooling fan
The service life of the cooling fan of the VFD is more than 25,000 hours. The actual service life of the
cooling fan is related to the use of the VFD and the temperature in the ambient environment.
You can view the running duration of the VFD through P07.14 (Accumulated running time).
The increase of the bearing noise indicates a fan fault. If the VFD is applied in a key position, replace
the fan once the fan starts to generate unusual noise. You can purchase spare parts of fans from
INVT.
Item
are in good contact.
Check whether the screws
and connectors loose.
Check whether there is
unusual smell or
discoloration.
Check whether there are
cracks, damage, deformation,
or rust.
Check whether there is
electrolyte leakage or
deformation.
Check whether there are
unusual sounds or vibration.
Check whether the bolts
loose.
Check whether there is
discoloration caused due to
overheat.
Check whether there are
foreign matters blocking or
attached to the cooling fan, air
inlets, or air outlets.
Maintenance and hardware fault diagnosis
Method
Screw them up.
Olfactory and visual
inspection
Visual inspection
Visual inspection,
and determine the
service life based on
the maintenance
information.
Auditory and visual
inspection, and turn
the fan blades with
your hand.
Screw them up.
Visual inspection,
and determine the
service life based on
the maintenance
information.
Visual inspection
-260-
Criterion
occurs.
No exception
occurs.
No exception
occurs.
No exception
occurs.
No exception
occurs.
The rotation is
smooth.
No exception
occurs.
No exception
occurs.
No exception
occurs.
