Motor Parameter - INVT Goodrive350 Series Operation Manual

Goodrive350 series high-performance multifunction VFD
Function
code
Source of upper
P03.19 limit setup of
braking torque
Set upper limit of
the torque when
P03.20
motoring via
Set upper limit of
P03.21 braking torque via
Motor output
P17.09
Torque reference
P17.15

5.5.6 Motor parameter


Check the safety conditions surrounding the motor and load machineries
before autotuning as physical injury may occur due to sudden start of motor during
Name
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET communication
10: PLC
11: Reserved
Note: For setting sources 1–4 and 8, 100%
corresponds to three times the rated motor
current.
0: Keypad (P03.21)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET communication
10: PLC
11: Reserved
Note: For setting sources 1–4 and 8, 100%
corresponds to three times the rated motor
current.
0.0–300.0% (rated motor current)
keypad
0.0–300.0% (rated motor current)
keypad
-250.0–250.0%
torque
-300.0–300.0% (rated motor current)
value
Description
-71-
Basic operation instructions
Default
value
0
180.0%
180.0%
0.0%
0.0%
