P06.17 Lower limit of AO1 output
Corresponding AO1 output of
P06.18
P06.19 Upper limit of AO1 output
Corresponding AO1 output of
P06.20
P06.21 AO1 output filter time
P06.22–
Name
lower limit
upper limit
Reserved variable
Description
17: Value 2 set through
PROFIBUS/CANopen/DeviceNet (0–
1000)
18: Value 1 set through Ethernet 1 (0–
1000)
19: Value 2 set through Ethernet 2 (0–
1000)
20: HDIB input (0.00–50.00kHz)
21: Value 1 set through
EtherCat/Profinet/EtherNetIP (0–1000)
22: Torque current (bipolar, 0–Triple
the motor rated current)
23: Exciting current (bipolar, 0–Triple
the motor rated current)
24: Set frequency (bipolar, 0–Max.
output frequency)
25: Ramp reference frequency (bipolar,
0–Max. output frequency)
26: Rotational speed (bipolar, 0–Speed
corresponding to max. output
frequency)
27: Value 2 set through
EtherCat/Profinet/EtherNetIP (0–1000)
28: C_AO1 (Set P27.00 to 1. 0–1000)
29: C_AO2 (Set P27.00 to 1. 0–1000)
30: Rotational speed (0–Twice the
motor rated synchronous speed)
31: Output torque (Actual value, 0–
Twice the motor rated torque)
32–47: Reserved
-300.0%–P06.19
0.00V–10.00V
P06.17–300.0%
0.00V–10.00V
0.000s–10.000s
0–65535
